High-speed Two-head Tracking Filling Machine

This Taiyang high-speed two-head tracking filling and capping machine has an efficient two-head design and can perform filling operations at the same time, greatly improving production efficiency. Taiyang high-speed two-head tracking filling and capping machine with advanced tracking technology, it can accurately control the filling volume, and ensure the accuracy and stability of filling for both low-viscosity and high-viscosity liquids. Taiyang high-speed two-head tracking capping machine is suitable for products such as cream, shampoo, liquid soap, lubricating oil, and motor oil. Taiyang high-speed two-head tracking capping machine has fast filling speed, high production efficiency,easy maintenance and a wide range of applications.Taiyang high-speed two-head tracking capping machine can be integrated with the capping machine and labeling machine on the bottling line, and has complete functions, which not only saves manpower and time costs, but also its intelligent operation control system makes the entire production process more convenient and efficient. Taiyang machinery is the ideal choice for modern production lines.

Technical Parameter

Performance And Features

1.Suitable for different bottle shapes and products, like liquid soap, detergent, shampoo, hair conditioner etc.

2.Automatic PLC control system, easy setting parameters on HMI,easy to operate.

3.Intelligent recipe save function for different products,easy to change products.

4.Servo filling system with higher filling accuracy, piston cylinder independent control, volume also can be adjusted separately

5..Equipped with double head high speed capping system, torque adjustable, pump head can be positioned

6. Optional product hopper with Sign glass window, CIP clean system and Material Level Controller

7.All contact parts adopt SUS316, other parts use SUS304

Application

Taiyang high-speed double-head tracking filling and capping machine is widely used in different kinds of product filling, such as, shampoo, shower gel, hand cleaning gel, laundry detergent and many other daily chemical products,etc. At a viscosity of around 1000, the filling machine can achieve maximum performance

Product details

Using servo filling, high filling accuracy.

Two piston cylinders are independently controlled.Each filling nozzle can be controlled separately.

Double screw capping reduces capping time and ensures each cap is screwed tightly

The chain conveyor belt is with large loading capacity,it can transport bottles faster and stably The guard rail for conveyor belt can be adjusted according to bottle diameter.
