Two-head Large-capacity Weighing Filling Machine

This Taiyang two-head large-capacity weighing filling machine is suitable for the production needs of large-capacity barreled products about 20L. This double-head large-capacity weighing filling machine equipped with an efficient roller conveyor line and can smoothly convey barreled products. The core highlight of this Taiyang two-head large-capacity weighing filling machine is its precise weighing function. It monitors the weight in real time during the filling process, with accurate measurement and good stability. Once the product in the barrel reaches the set weight, the filling machine will immediately stop the filling operation to ensure that the filling amount of each barrel is accurate. The Taiyang two-head large-capacity weighing filling machine pump filling design greatly improves the filling efficiency. The two filling heads can work at the same time, the filling method is flexible, the filling speed is fast, and it is not affected by the viscosity and temperature of the oil. Whether it is barreled water, edible oil and other products in the food industry, or barreled laundry detergent, disinfectant, glass water, paint, etc., in the daily chemical industry, Taiyang two-head large-capacity weighing filling machine can be perfectly adapted.Taiyang machinery can achieve efficient and stable filling work, provide reliable equipment guarantee for the company's automated production, help improve production efficiency, reduce costs, and ensure product quality.

Technical Parameter

Performance And Features

1.It uses a programmable controller (PLC), touch screen, and weighing instrument for operation and control, and is easy to use and adjust. Users can freely switch modes, and select barrel parameters and filling volume on the touch screen for the parameter memory function of products with different specifications. The operation is simple and intuitive, and the current time, operating status, cumulative output, etc. are displayed at the same time.
2.The main body is a stainless steel environmentally friendly frame and an acrylic door; all valves and interface seals are made of polytetrafluoroethylene, which can meet the complex operating environment of alternating hot and cold conditions.
3.As for the connection method of each pipeline, it adopts quick-installation connection and comes with its own cleaning program for easy disassembly and cleaning.
4..All contact parts adopt SUS316, other parts use SUS304

Application

This Taiyang two-head large-capacity weighing filling machine is suitable for the production needs of large-capacity barreled products about 20L. It can fill barreled water, edible oil, laundry detergent, disinfectant, glass water, lubricating oil, foliar fertilizer, purified water, antifreeze, and other materials.

Product details

It adopts magnetic pump filling, which has quick response and two filling heads can work at the same time. It is equipped with sensors and will not start filling until the product is recognized.

Accurate weighing,once the product in the barrel reaches the set weight, the filling machine will immediately stop the filling operation to ensure that the filling amount of each barrel is accurate.

Equipped with a large-capacity hopper to accommodate more materials at one time, reducing the number and time of frequent refilling

The slap lid device will first press the bottle cap to make it initially fit against the bottle mouth, forming a preliminary sealing state. The mold sleeve capping device will then tightly screw the bottle cap onto the bottle mouth, ensuring that the bottle cap and the bottle mouth fit tightly together, forming a more solid and reliable sealing effect, effectively preventing liquid leakage or external contaminants from entering the bottle during transportation and storage.

This roller conveyor line can rotate at a constant speed under the stable drive of the motor. With its reliable performance and strong carrying capacity, it can transport all kinds of items smoothly and efficiently.
